Monitor Your Energy Bill via Modbus, MKR WiFi 1010 and RS485

Connect a Modbus energy meter to an Arduino and monitor power consumption via Home Assistant.

IntermediateFull instructions provided14,695
Monitor Your Energy Bill via Modbus, MKR WiFi 1010 and RS485

Things used in this project

Hardware components

Arduino MKR WiFi 1010
Arduino MKR WiFi 1010
×1
Arduino MKR 485 Shield
Arduino MKR 485 Shield
×1
USB-A to Micro-USB Cable
USB-A to Micro-USB Cable
×1
USB Power Supply
Any power supply compatible. The MKR485 shield has a 7-24V buck converter built in.
×1
Twisted single pair shielded cable
×1

Software apps and online services

Home Assistant
Home Assistant
Arduino Web Editor
Arduino Web Editor
MQTT
MQTT

Hand tools and fabrication machines

Mastech MS8217 Autorange Digital Multimeter
Digilent Mastech MS8217 Autorange Digital Multimeter
Electrician Scissors
Small flathead screwdriver
for MKR485 terminals
Medium size philips screwdriver

Story

Read more

Code

Modbus RTU to MQTT bridge for Finder

This sketch provides a full bridge between the finder energy meter and mqtt. Developed to monitor electricity costs and usage in Casa Jasmina.
